B.Sc. Thesis · BRAC University · Grade A · 2026

C-MAT: Cross-Modal Aligned Transformer

A four-class model that separates Alzheimer's disease, frontotemporal dementia, Parkinson's disease, and healthy controls using structural MRI and resting-state EEG together, and keeps working when a patient has only one of the two.

Team thesis with Sharika Salim, Tonmoy Pal, and Rubayet Hassan Rupom · Supervised by Dr. Chowdhury Mofizur Rahman and Dr. Md. Golam Rabiul Alam

[ EVD ]

Engineering evidence

My contribution
Thesis co-author · Architecture, data pipeline, training, and evaluation
Outcome
Defended May 2026 · Grade A · IEEE-format paper prepared
Decision record 01
Rendered EEG features as images so a single pretrained vision backbone could serve both modalities, rather than training a separate EEG network on a few hundred recordings.
[ RES ]

Key results

Macro F1 · ConvNeXt-Tiny
0.611
± 0.029 · subject-level stratified 5-fold CV, four classes
Paired MRI + EEG subset
0.702
Macro F1 on 25 strictly paired subjects, vs 0.482 for late fusion
Subjects
1,102
10 open datasets from seven countries
Focal vs cross-entropy
+0.048
Macro F1 gain from class-balanced focal loss (fold-0 ablation)
[ ARC ]

Architecture

Both modalities are turned into images so one pretrained vision backbone can read them. Each patient's slices or EEG epochs are pooled with learned attention, and a sigmoid gate decides per patient how much to trust MRI versus EEG. A learnable null token stands in for whichever modality is missing.

  1. 01

    Cohort & splits

    Ten heterogeneous open datasets merged into one audited manifest.

    • Dataset-prefixed subject IDs
    • Subject-level stratified 5-fold
    • No subject in train and test

  2. 02

    MRI pipeline

    T1-weighted volumes normalised across scanners.

    • 1 mm resampling, Otsu brain mask
    • 14 slices: 7 axial, 4 coronal, 3 sagittal
    • CLAHE → 3 × 224 × 224

  3. 03

    EEG pipeline

    Resting-state recordings mapped to 19 standard channels.

    • 256 Hz, 1–45 Hz, ICA + ICLabel
    • 2 s epochs → 38 features per channel
    • Pseudo-image and tabular paths

  4. 04

    Shared encoder

    One pretrained timm backbone for both modalities.

    • ConvNeXt-Tiny or DeiT
    • Attention pooling over slices / epochs
    • EEG feature MLP (19 × 38)

  5. 05

    Gated fusion

    Sigmoid gate mixes the two embeddings per patient.

    • Learnable null token per modality
    • Class-balanced focal loss + MixUp
    • AD · FTD · PD · HC

  6. 06

    Explainability

    • Grad-CAM on MRI slices
    • Fusion gate values by class
[ KEY ]

Technical highlights

  1. 01

    Audited the pipeline through three versions (V1 → V3), fixing subject-ID collisions between datasets, preprocessing reuse, and baseline fairness before trusting any number.

  2. 02

    Handled missing modalities with learnable null tokens instead of imputation, so subjects with only MRI or only EEG still train the shared model.

  3. 03

    Made fusion inspectable: the gate value shows how much the model relied on MRI versus EEG for each class.

  4. 04

    Compared against honest baselines: EEG power spectrum + SVM (0.309) and EEG random forest (0.453).

[ LIM ]

Limits & lessons

  • Research and education only. The model is not a clinical diagnostic tool.
  • A strong MRI-only baseline stays competitive on single folds; fusion's clearest gain is on strictly paired subjects (0.702 vs 0.482), which are few.
  • The thesis text and figures are © BRAC University, so this page describes the method in my own words instead of reproducing them.
[ STK ]

Stack

  • Python
  • PyTorch
  • timm
  • ConvNeXt
  • DeiT
  • MNE
  • nibabel
  • scikit-learn
  • Optuna
